5/16" ASAHI SUNAC AQ810‑3
Have one to sell?
ConditionUsed
1 available
• AQ810‑3 is part of Sunac’s 800‑series mid‑size headers.
• Ideal for automotive fasteners, small bolts, and precision formed parts.
• Production capacity varies with material tensile strength and part geometry.
• Specs based on factory AQ‑Series documentation.
ASAHI SUNAC – AQ810‑3 COLD HEADER
---------------------------------
MODEL: AQ810‑3
TYPE: 3‑Die, 3‑Blow Cold Header
MECHANICAL SPECIFICATIONS
-------------------------
Max Cutoff Diameter: 8 mm (5/16")
Max Cutoff Length: 127 mm (5")
Max Kickout Length: 100 mm (4")
Die Hole Diameter × Depth: 64 × 140 mm (2.5 × 5.5")
Punch Hole Dia × Depth: 50 × 115 mm 2 × 4.4")
PKO Stroke: 15 mm (19/32")
Punch Front Dead Center: 25 mm (1")
Total Forging Force: 60 tons
Production Capacity (max): 265 pcs/min
Main Motor Power: 22 kW
• AQ810‑3 is part of Sunac’s 800‑series mid‑size headers.
• Ideal for automotive fasteners, small bolts, and precision formed parts.
• Production capacity varies with material tensile strength and part geometry.
• Specs based on factory AQ‑Series documentation.
ASAHI SUNAC – AQ810‑3 COLD HEADER
---------------------------------
MODEL: AQ810‑3
TYPE: 3‑Die, 3‑Blow Cold Header
MECHANICAL SPECIFICATIONS
-------------------------
Max Cutoff Diameter: 8 mm (5/16")
Max Cutoff Length: 127 mm (5")
Max Kickout Length: 100 mm (4")
Die Hole Diameter × Depth: 64 × 140 mm (2.5 × 5.5")
Punch Hole Dia × Depth: 50 × 115 mm 2 × 4.4")
PKO Stroke: 15 mm (19/32")
Punch Front Dead Center: 25 mm (1")
Total Forging Force: 60 tons
Production Capacity (max): 265 pcs/min
Main Motor Power: 22 kW
