ASAHI SUNAC RH-60 2 Die 3 Blow
Have one to sell?
ConditionUsed
1 available
ASAHI SUNAC RH-60 used headers available. Max diameter: 8.5, Max length: 55.0. Ideal for precision tasks and engineered for performance. Great addition to any manufacturing operation seeking reliable equipment.
RH60 SPECIFICATIONS
-------------------
Model: RH‑60
Design: 2‑Die, 3‑Blow
Max Cutoff Diameter: 8 mm (5/16")
Max Cutoff Length: 55 mm (2-3/16")
Kickout Length 1st: 55 mm (2-3/16")
Kickout Length 2nd: 55 mm (2-3/16")
PKO Stroke 2nd: 18 mm (22/32")
PKO Stroke 3rd: 12 mm (1/2")
Die Hole (1st): 48 × 100 mm (1-7/8 × 4")
Die Hole (2nd): 48 × 100 mm (1-7/8 × 4")
Punch Hole (1st): 20 × 72 mm (3/4 × 2-52/64")
Punch Hole (2nd/3rd):35 × 70 mm (1-3/8 × 2-3/4")
Cutoff Quill Dia: 20 mm (3/4")
Die Center Distance: 55 mm (2-3/16")
Front Dead Center: 22 mm (7/8")
Forging Power: 30 tons
Max Production Rate: 200 pcs/min
Main Motor: 7.5 kW
Machine Dimensions: 4000 × 1600 × 1800 mm
Machine Weight: 5.5 tons
ASAHI SUNAC RH-60 used headers available. Max diameter: 8.5, Max length: 55.0. Ideal for precision tasks and engineered for performance. Great addition to any manufacturing operation seeking reliable equipment.
Imperial
| Max Diameter | 0.3346" |
| Max Length | 2.1654" |
RH60 SPECIFICATIONS
-------------------
Model: RH‑60
Design: 2‑Die, 3‑Blow
Max Cutoff Diameter: 8 mm (5/16")
Max Cutoff Length: 55 mm (2-3/16")
Kickout Length 1st: 55 mm (2-3/16")
Kickout Length 2nd: 55 mm (2-3/16")
PKO Stroke 2nd: 18 mm (22/32")
PKO Stroke 3rd: 12 mm (1/2")
Die Hole (1st): 48 × 100 mm (1-7/8 × 4")
Die Hole (2nd): 48 × 100 mm (1-7/8 × 4")
Punch Hole (1st): 20 × 72 mm (3/4 × 2-52/64")
Punch Hole (2nd/3rd):35 × 70 mm (1-3/8 × 2-3/4")
Cutoff Quill Dia: 20 mm (3/4")
Die Center Distance: 55 mm (2-3/16")
Front Dead Center: 22 mm (7/8")
Forging Power: 30 tons
Max Production Rate: 200 pcs/min
Main Motor: 7.5 kW
Machine Dimensions: 4000 × 1600 × 1800 mm
Machine Weight: 5.5 tons
